DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform

DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform

  • DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform
  • DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform
  • DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform
  • DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform
DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform
Product Details:
Place of Origin: Original of China
Brand Name: BestMax
Certification: CE ISO9001:2008 IPAF member
Model Number: MX580RN
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 day after receipt of deposit
Payment Terms: T/T, L/C
Supply Ability: 100 sets/ month
Contact Now
Detailed Product Description
Model: MX580RN Material: Q345 Steel
Platform Size: 1.67*0.74m Measurement: 1.81*0.76*1.82m
Battery: 4*6V/210Ah Total Weight: 1385kg
Color: Green, Customized Color Is Available Working Height: 7.8m
Platform Height: 5.8m Gradeability: 25%
Loading Capacity: 230kg
High Light:

self propelled lift

,

scissor lift self propelled



DC Motor Driving Self Propelled Scissor Lift Aerial Installation and Construction



Description:



Bestmax Self-propelled Electric Scissor Lift (DC motor driving) is ideal for assisting finish various aerial work tasks in different situations to improve work efficiency. It has excellent structure, smooth driving, faster speed, lower noise, friendly to environment, deeply loved by users who always work outdoor, to provide you with a flexible mobility, operability. Suitable for rough-terrain ground, solid tires make the work more stability. Fully proportional control system, make the operate more easily. Stronger power, it can reach safe work height of 14m and unique in carrying capacity and wide platform that can bring more workers and tool set. With it to assist finish various aerial work tasks in different situations, work efficiency will be greatly improved.



Parameters



Model

MX580RN

Load capacity

230kg

Extension load capacity

113kg

Max Worker number

2

Working height

7.8m

Platform floor height

5.8m

Measurement

1.81*0.76*1.82m

Extension platform size

1.67*0.74m

Ground clearance(stowed)

0.9m

Ground clearance(raised)

0.09m

Wheel base 1.36m

Turning Radius(inside)

0m

Turning Radius(outside)

1.64m

Lifting Motor 24V/2kw
Drive motor 24V/0.5kw
Travelling speed(stowed) 4.5km/h
Travelling speed(raised) 0.8km/h
Lifting/ lowering speed 27/22sec
Batteries 4*6V/210Ah
Charger 24V/ 25A
Gradeability 25%
Max working slop 1.5°/3°
Tyre 12*4
Weight 1385kg



Flexible Operation

Fully proportional control, either lifting or moving, all can easily operating in the joystick. Zero inside turning radius, allowing users to use in a narrow space, and also facilitate changing positions. It has two kinds of moving speed to secure move quickly and lift safe.



Easy Maintenance

It give full consideration to the convenience of the user in their daily work. It has fault diagnosis system help the user can find the failure point one time. And also reduce the losses caused by forgotten maintenance.



Traceless tire

Configured with traceless tire to protect the ground surface and suitable for indoor application. The wheels and tires are very very tough and rigid able to travel through uneven terrain and rough surface



Platform Swing Gate

Platform Swing Gate make enter and out space more large, no restrictions to the guardrails.

Fold-able guardrail make the machine can be easily through standard doors when move during working area.



Airway tube to platform

User can be optional airway tube to platform to make sure pneumatic tools and equipment can be used in the platform.



AC wiring to platform

AC wiring and socket to platform to meet the customers demand to make sure the electic tools can be used in the platform.



Key-type lock sliding

Key-type lock sliding door to protect misuse by not equipment keeper, particularly suitable for protect the electrical components when the rent out



Platform work light (optional)

The professional platform work lights allows construction of the user easier lighting and operating



Motion alarm and Horn

The machine is equipped with motion alarm and horn when mowing to remind around person to take necessary precaution.



Safety Precaution:

  • Auxiliary lowering device
  • Auto-brake system
  • Tilting protection system
  • Automatic pothole protection
  • Emergency stop button
  • Charging protection system
  • Auto-lock door on platform
  • Overload protection sensor with alarm (optional)



DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform 0









DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform 1DC Motor Driving 5.8m Self-propelled Heavy Duty Scissor Lift Loading Capacity 230kg with Extension Platform 2



Why choose Bestmax Propelled Scissor Lift?


· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· One year warranty



Thank you for your reading and welcome your inquiry. We will respond you as soon as possible.
