5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function

5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function

    • 5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function
    • 5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function
    • 5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function
    • 5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function
  • 5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function

    Product Details:

    Place of Origin: Original of China
    Brand Name: Bestmax Lift
    Certification: CE ISO9001:2008 IPAF member
    Model Number: MX580S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Wrapped in pallets/ wooden case
    Delivery Time: 30 day after receipt of deposit
    Payment Terms: T/T, L/C
    Supply Ability: 100 sets/ month
    Contact Now
    Detailed Product Description
    Model: MX580S Lift Capacity: 230kg
    Platform Size: 1.64*0.75m Extension Loading: 113kg
    Total Weight: 1470kg Material: Q345 Steel
    Driving: Hydraulic Motor





    5.8 Meters Lifting Height Self Propelled Scissor Lift Aerial Work Platform



    Description:



    Self propelled scissor lift, with automatic walking function, can be in different work condition, do not need external power supply, do not need artificial traction.

    Mobile flexible, convenient operation, lift freely, only one people can finish forward, backward, steering, fast and slow walk, easily moved, spacious working platforms, high working efficiency.

    Scissor lift can be move while extended and controlled from platform by the operator.

    Most models are equipped with zero inside turning radius capability, can be easily and flexibly operated in crowed working conditions such as construction site,elevator, and narrow corridor. Lift-down, turning, forward and backward movements can be easily operated by one person.



    Parameters



    Model

    MX580S

    Load capacity

    230kg

    Extension load capacity

    113kg

    Max Worker number

    2

    Working height

    7.8m

    Platform floor height

    5.8m

    Measurement

    1.83*0.81*1.71m

    Extension platform size

    1.64*0.75m

    Ground clearance(stowed)

    0.1m

    Ground clearance(raised)

    0.019m

    Wheel base 1.36m

    Turning Radius(inside)

    0m

    Turning Radius(outside)

    1.64m

    Lifting / drive motor 24V/3.3kW
    Travelling speed(stowed) 3.0km/h
    Travelling speed(raised) 1.0km/h
    Lifting/ lowering speed 18/22 sec
    Batteries 4*6V/225Ah
    Charger 24V/ 30A
    Gradeability 25%
    Max working slope 1.5°/3°
    Tyre Size 305*100
    Weight 1470kg



    All Specification

    Model MX580S MX600SN MX800SN MX800S MX1000S MX1200S
    Load 230 kg 230 kg 230 kg 450 kg 320 kg 230 kg
    Extension Load 113 kg 113 kg 113 kg 113 kg 113 kg 113 kg
    Platform Height 5.8 m 6 m 8 m 8 m 10 m 11.8 m
    Working Height 7.8 m 8 m 10 m 10 m 12 m 13.8 m
    Platform Size 1.67*0.74m 2.27*0.81m 2.27*0.81m 2.27*1.12m 2.27*1.12m 2.27*1.12m
    Platform Extension Length 0.9 m 0.9 m 0.9 m 0.9 m 0.9 m 0.9 m
    Lift/Drive Motor 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/4.5 kw




    Safety Precaution

    • Auxiliary Lowering Devices
    • Anti-burst System
    • Emergency Stop Button
    • Tilting Protection System
    • Charging Protection System
    • Automatic Pothole Protection
    • Automatic Braking System
    • Buzzer and Horn



    Product Details

    5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function



    5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function

    Other Related Products

    5.8 Meters Lifting Height Self Propelled Scissor Lift With Automatic Walking Function



    Why choose Bestmax Lift Self Propelled Scissor Lift?



    · High Quality product
    · Reasonable Price
    · Easy payment mode
    · Timely delivery
    · Good after Service
    · Client-centric approach
    · One year warranty
