14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity

14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity

  • 14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity
14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity
Product Details:
Place of Origin: Original of China
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: MX1200S
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 day after receipt of deposit
Payment Terms: T/T, L/C
Supply Ability: 100 units/ month
Contact Now
Detailed Product Description
Loading Capacity: 230Kg Platform Size: 2.27*1.12m
Platform Height: 11.8m Working Height: 13.8m
Exension Load Capacity: 113kg Extension Length: 0.90m
Lift/Drive Motor: 24V/3.3kw Overall Size: 2.43* 1.15*2.03m
Weight: 2820kg
High Light:

self propelled work platform

,

self propelled lift



14m Working Height CE Certified Self Propelled Scissor Lift with 230kg Load Capacity



Description:

1. Self propelled scissor lift, with automatic walking function, can be in different work condition, do not need external power supply, do not need artificial traction.

2. Mobile flexible, convenient operation, lift freely, only one people can finish forward, backward, steering, fast and slow walk, easily moved, spacious working platforms, high working efficiency.

3. Scissor lift can be move while extended and controlled from platform by the operator.

4. Most models are equipped with zero inside turning radius capability, can be easily and flexibly operated in crowed working conditions such as construction site, elevator, and narrow corridor. Lift-down, turning, forward and backward movements can be easily operated by one person.


Specification
Model MX580S MX600SN MX800SN MX800S MX1000S MX1200S
Load 230 kg 230 kg 230 kg 450 kg 320 kg 230 kg
Extension Load 113 kg 113 kg 113 kg 113 kg 113 kg 113 kg
Platform Height 5.8 m 6 m 8 m 8 m 10 m 11.8 m
Working Height 7.8 m 8 m 10 m 10 m 12 m 13.8 m
Platform Size 1.67*0.74m 2.27*0.81m 2.27*0.81m 2.27*1.12m 2.27*1.12m 2.27*1.12m
Platform Extension Length 0.9 m 0.9 m 0.9 m 0.9 m 0.9 m 0.9 m
Lift/Drive Motor 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/3.3 kw 24v/4.5 kw





Standard Configuration:

proportional control                             Auto-brake system

Auto-lock door on platform                  Extension Platform

Drivable when lifted                             Traceless tire

4 x 2 Driving                                        Auxiliary lowering device

Emergency stop button                       Horn

Fault diagnosis system                       Tilting protection system

Action buzzer                                      Time Recorder

Supporting bar                                    Fork Lift Slot

Charging protection system                strobe light

Detachable fence                                Automatic pothole protection



Optional Configuration:

  • Overload protection sensor with alarm
  • DC Power connection to the platform
  • Working light on the platform
  • Airway tube to the platform



14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity 0

14m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity 114m Working Height CE Certified Self Propelled Scissor Lift With 230kg Load Capacity 2

Why choose Our Self Propelled Scissor Lift?
· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· One year warranty



Our Service
1. We can design the customized the machines based on your requirement.
2. After knowing your detailed need, the right models will be recommened to you with good price.
3. Shipment can be arranged from our port to your destination port.
4. Opetion video can be sent to you if needed.
5. Parts of machines can be sent to you by express within 7 days if needed.



Thank you for your reading and welcome your inquiry. We will respond you as soon as possible.
