Place of Origin: | China |
Brand Name: | CHEN LIFT |
Certification: | CE ISO9001:2008 IPAF member |
Model Number: | MX800SN |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiable |
Packaging Details: | Wrapped in pallets/ wooden case |
Delivery Time: | 30 days after receipt of deposit |
Payment Terms: | T/T, L/C |
Supply Ability: | 100 sets/ month |
Platform Size: | 2.27*0.81m | Measurement: | 2.43*0.81*1.87m |
---|---|---|---|
Platform Height: | 8m | Loading Capacity: | 230Kg |
Working Height: | 10m | Power Source: | 4*6V/ 225Ah |
Highlight: | self propelled work platform,scissor lift self propelled |
Hydraulic Motor Drive Self Propelled Scissor Lift Table 8m High Aerial Work Platform
Description:
Fully proportional control system, larger loading capacity, reach further with extensible platform, solid tough tire make it more competent assist finish various aerial work tasks in different situations more efficiently. Powerful, intelligent and flexible for aerial work and material handling. It does not need any outriggers, one man operates on the working platforms;
Moving forward and backward, turning around and lifting up are easily operated. Short chargeable time and long dual time of the battery; Easily moved, spacious working platforms, smooth working condition and high working efficiency. Moving method: The chargeable battery provides the power to move and steer around.
Parameters:
Model |
MX800SN |
Load capacity |
230kg |
Extension load capacity |
113kg |
Max Worker number |
2 |
Working height |
10m |
Platform floor height |
8m |
Measurement |
2.43*0.81*1.87m |
Extension platform size |
2.27*0.81m |
Ground clearance(stowed) |
0.1m |
Ground clearance(raised) |
0.019m |
Wheel base | 1.87m |
Turning Radius(inside) |
0m |
Turning Radius(outside) |
2.1m |
Lifting / drive motor | 24V/3.3kw |
Travelling speed(stowed) | 3.0km/h |
Travelling speed(raised) | 1.0km/h |
Lifting/ lowering speed | 40/30sec |
Batteries | 4*6V/225Ah |
Charger | 24V/ 30A |
Gradeability | 25% |
Max working slop | 1.5°/3° |
Tyre | 15*5 |
Weight | 2100kg |
Flexible Operation
Fully proportional control, either lifting or moving, all can easily operating in the joystick. Zero inside turning radius, allowing users to use in a narrow space, and also facilitate changing positions. It has two kinds of moving speed to secure move quickly and lift safe.
Built-In Safety Features
It can be controlled from either the ground or platform and has a battery charge indicator . It also has an emergency stop button, a descent alarm, an electronic horn, and a manual platform lowering valve for safety
Easy Maintenance
It give full consideration to the convenience of the user in their daily work. It has fault diagnosis system help the user can find the failure point one time. And also reduce the losses caused by forgotten maintenance.
Platform Swing Gate
Platform Swing Gate make enter and out space more large, no restrictions to the guardrails.
Fold-able guardrail make the machine can be easily through standard doors when move during working area.
Airway tube to platform
User can be optional airway tube to platform to make sure pneumatic tools and equipment can be used in the platform
AC wiring to platform
AC wiring and socket to platform to meet the customers demand to make sure the electric tools can be used in the platform.
Key-type lock sliding
Key-type lock sliding door to protect misuse by not equipment keeper, particularly suitable for protect the electrical components when the rent out
Platform work light (optional)
The professional platform work lights allows construction of the user easier lighting and operating
Motion alarm and Horn
The machine is equipped with motion alarm and horn when moving to remind around person to take necessary precaution.
Standard Configuration:
Proportional control Auto-brake system
Auto-lock door on platform Extension Platform
Drivable when lifted Traceless tire
4 x 2 Driving Auxiliary lowering device
Emergency stop button Horn
Fault diagnosis system Tilting protection system
Action buzzer Time Recorder
Supporting bar Fork Lift Slot
Charging protection system Strobe light
Detachable fence Automatic pothole protection
Optional Configuration:
Why choose CHEN LIFT Self Propelled Scissor Lift?
· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· One year warranty
Thank you for your reading and welcome your inquiry. We will respond you as soon as possible.
Contact Person: Mr. Aijun Liu
Tel: 0086-13951119762
Fax: 86-512-67339762
