8m Self-propelled Scissor Lift For Work At Height With 230Kg Loading Capacity

8m Self-propelled Scissor Lift For Work At Height With 230Kg Loading Capacity
8m Self-propelled Scissor Lift For Work At Height With 230Kg Loading Capacity

Large Image :  8m Self-propelled Scissor Lift For Work At Height With 230Kg Loading Capacity

Product Details:

Place of Origin: China
Brand Name: CHEN LIFT
Certification: CE
Model Number: MX800SN

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets
Delivery Time: 30 days after receipt of deposit
Payment Terms: T/T L/C
Supply Ability: 100 sets/month
Detailed Product Description
Loading Capacity: 230Kg Platform Height: 8m
Platform Size: 2.27*0.81m Working Height: 10m
Lift/Drive Motor: 24V/3.3Kw Power Source: 4*6V/225Ah
High Light:

self propelled work platform


self propelled lift


8m Self-propelled Scissor Lift with 230Kg


Quick Detail:

Name Self-propelled Scissor Lift Brand Name CHEN LIFT
Loading Capacity 230Kg Platform Height 8m
Platform Size 2.27*0.81m Color Red Color or Optional
Gradeability 25% Wheelbase 1.87m
Weight 2100Kg Power Source 4*6V / 225AH

Self-propelled scissor lifts are also called as Electric Scissor lifts or electric elevated work platform; they are used to provide temporary access for contractors to high, inaccessible areas on a variety of job sites such as maintenance and construction work. They are designed to lift limited weights and capable of being fully operated by a single person. It is unique in carrying capacity and a wide platform that can bring more workers and tool set, whether indoors or outdoors.

Main Features:


1. Roll-out extension platform provide more workspace.

2. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.

3. Different models are available with the maximum working height at 6m to 16m

4. Zero-turn radius and compact design provide access in and around confined work areas.

5. 25% grade ability when driving on slopes.

6. On-board diagnostic help operators troubleshoot on the fly and make adjustments in the field to maximize uptime

7. Single extension platform provide more workspace.

8. Manganese steel lifting arm in high strength with rectangle shape

9. The antiskid design endows the platforms with excellent antiskid property

10. The control panels are available on the platforms and ground.

11. Fine grinding cylinder in good sealing performance

12. Equipped with safeguard valve to avoid hydraulic pipe rupture

13. Swing-out tray for easy maintenance access



Model MX800SN
Load capacity 230kg
Extension load capacity 113kg
Max Worker number 2
Working height 10m
Platform floor height 8m
Measurement 2.43*0.81*1.87m
Extension platform size 2.27*0.81m
Ground clearance(stowed) 0.1m
Ground clearance(raised) 0.019m
Wheel base 1.87m
Turning Radius(inside) 0m
Turning Radius(outside) 2.1m
Lifting / drive motor 24V/3.3kw
Travelling speed(stowed) 3.0km/h
Travelling speed(raised) 1.0km/h
Lifting/ lowering speed 40/30sec
Batteries 4*6V/225Ah
Charger 24V/ 30A
Gradeability 25%
Max working slop 1.5°/3°
Tyre 15*5
Weight 2100kg


  • Standard detachable platform
  • Extended platform
  • Proportional controls for lift and drive functions
  • Automatic 25Amp battery charger provides strong power for vehicle
  • Safe distance protection when the platform lowering down
  • Manual emergency platform lowing valve. When there is no power the machine can lower down safely.
  • Emergency stops are at both platform and ground control boxes.
  • Drive speed interlock limits speed while elevated
  • Multiple disc brakes provide smooth deceleration
  • When there is no power manual brake release function can move the machine under the circumstance when there is no other forklift, lifting equipment and so on.
  • Pothole guards protect the machine from tilting down when the machine moving on the raised position
  • Non-marking tires make sure there is no damage and no marks on the ground
  • AC wiring to platform
  • Tilt level sensor with audible alarm
  • Beeper horn
  • Hour meter
  • Safety brackets
  • Battery charge indicator
  • Forklift sockets
  • Diagnosis system
  • Fault code display

Optional Configuration:

  • Fold-able guardrail
  • Motion alarm
  • Platform swing gate
  • Air line to platform
  • Dual flashing beacon
  • Maintenance-free battery
  • Horn
  • Platform work lights
  • Key-type lock sliding door
  • Anti-collision system
  • Head protection stop system

1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.
2. Aerial Working Purpose: machine maintenance, painting, cleaning etc



Why choose CHEN LIFT Self-propelled Scissor Lift?

  • Much quieter

All Bestmax self-propelled scissor lift adopt high-performance battery power, pollution-free and no emissions, low noise electric pump, can also be used even in the area of high environmental requirements, such as office buildings, hotel, hospital, school and so on.

  • Flexible Operation

Fully proportional joystick control, either lifting or moving, all can easily operate in the joystick.
Zero inside turning radius allowing users to use in a narrow space, and also facilitate changing positions.
Bestmax self-propelled scissor lift has two kinds of moving speed to secure move quickly and lift safely. All the scissor lifts have extended platforms which makes the operator get close to the work points much easier and breakthrough the space obstacles.

  • Easy maintenance

Bestmax self-propelled scissor lift give full consideration to the convenience of the users in their daily work maintenance. All the Self-propelled Scissor Lifts have fault diagnosis system, this makes the user can find the point of failure in one time. Door-open control box and battery box allow maintenance person to find the maintenance point quickly and easily. Also it is easier to change the spare parts. The scissor booms repair bracket, so that the user dose not need the help of lifting equipment, boom system can be easily overhaul.
