400Kg Loading Capacity Guide Rail Elevator

400Kg Loading Capacity Guide Rail Elevator

  • 400Kg Loading Capacity Guide Rail Elevator
  • 400Kg Loading Capacity Guide Rail Elevator
  • 400Kg Loading Capacity Guide Rail Elevator
400Kg Loading Capacity Guide Rail Elevator
Product Details:
Place of Origin: China
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: SJG0.4-4
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Model: Guide Rail Elevator Load Capacity: 400kg
Lifting Height: 4m
High Light:

cargo transport systems


Guide Rail Platform

400Kg Loading Capacity Guide Rail Elevator with 4 m Lifting Height
Quick Detail:

Name Guide Rail Platform Brand Name CHEN LIFT
Loading Capacity 400Kg Lifting Height 16m
Platform Size 1.2*1.8m Color Optional
Lifting Power 3.0Kw Power Supply AC
Minimum Height 200mm

Guide Rail Lift as an ideal cargo transport equipment is mainly used for cargo transportation between different floors, equipped with anti-falling interactive chain, overload protection, the control buttons are available every floor and the platform.
Main Features:
1. Large loading capacity, fluctuation floor interactive interlocking.
2. High hoisting capacity, with side cylinder, durable and long lasting.
3. Only four square meters required on the over storage, no larger places required.
4. Manual lowing when power off, emergency stop button, convenient, fast and practical.
5. Can be customized according to the environment, reasonable price, economical and practical.
6. Layer door can be well versed in, workshop can be mutual split, convenient, save a space;
7. Can be installed inside and outside, special circumstances with derrick, without foundation.
8. Especially suitable for 2-3 layer steel structure workshop.
Major Parameters:

  • Model: SJG0.4-4
  • Loading Capacity 400kg
  • Lifting Height 4000mm
  • Minimum Height 20mm
  • Platform Size 1200*1800mm
  • Lifting Power 3.0kw
  • Power Voltage 380V/50HZ
  • Cylinder Ф80(2Pcs)


  • Electric system: Schneider contactor, SANLICO button, CHNT electrical
  • Hydraulic System: NOK sealing
  • Platform Surface : Antiskid checkered plate
  • Platform Frame: Q345B Manganese steel and 100*40*4 rectangular tube
  • Guide Rail: 14# U Bar
  • High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose

1. Site: Work Shop, etc.
2. Aerial Working Purpose: cargo loading etc.
Why to choose CHEN LIFT Guide Rail Lift?

· High Quality

· Reasonable Price

· Good after Service

· 1 Year Warranty

· More Than 10 Years Experience
