3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse

3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse
3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse

Large Image :  3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse

Product Details:

Place of Origin: Original from China
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: MK300

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 days after receipt of deposit
Supply Ability: 200 units/ month
Detailed Product Description
Model: MK300 Lift Capacity: 240kg
Platform Height Max: 3m Working Height Max: 5m
Platform Size: 1.15m*0.6m Power Source: DC12V
Charger: 24V 12A Weight: 495kg
Color: Customizable Extension Platform: Optional Configuration
High Light:

scissor lift mobile

,

automobile scissor lift

3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift for Warehouse



Main Feature​



1.Pointing control of lifting up and down.
2.Manganese steel lifting arm in high strength with rectangle shape
3.Anti skid floor in platform
4 The control panels are available on the platforms and ground.
5. Fine grinding cylinder in good sealing performance
6.Neatly folding guardrails
7. Battery and battery charger in bulit
8. Optional extension platform



Safety Precautions​



1.The operation voltage on the platform is 24V
2.Emergency stop button on the paltform and ground
3.Auxiliary platform lowering
4.Hose burst valve safety
5.Rain-proof design electirc cabinet
6.Foldable fence on the platform


Parameters



Loading Capacity 240kg
Maximum Height(rails folded up) 3000mm
Minimum Heght(rails folded down) 1430mm
Minimum Heightt(rails folded up) 1830mm
Platform Size 1150*600mm
Lifting Power 0.8kw
Power Voltage DC12V
Lifting Time 34s
Cylinder Ф55(1Pc)
Battery 80Ah
Battery Charger 24V 12A
Extension platfirm(optional) 100mm
Ground Clearance 50mm
Gear Pump 4ml/r
Total Weight 495kg
Measurement 1320*760*1430mm





Configuration



Electric system Schneider contactor,SANLICO button,CHNT electrical
Hydraulic System Hycman power pack ,NOK sealing
Scissor Arm Support Hi-strength Maganese steel rectangle tube Q345 B
Platform Surface antiskid checkered plate
Driving Tyre 6inch and 8inch , two swivel and two fixed

High-pressure Oil Pipe

double wire hydraulic intensifier rubber hose



3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse 0

3m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse 13m Height Semi-Electric Mini Portable Manual Pushing Scissor Lift For Warehouse 2
