6 Meters Industrial Hydraulic Lift Platform Scissor Lift Aerial Work Platform 1 Ton Load

Product Details:

Place of Origin:	CHINA
Brand Name:	CHEN LIFT
Certification:	CE ISO9001:2008 IPAF member
Model Number:	MK600T

Payment & Shipping Terms:

Minimum Order Quantity:	one set
Price:	negotiable
Packaging Details:	FCL in pallets, LCL in Wooden Case
Delivery Time:	20 days
Supply Ability:	100 sets per month

Contact Now

Detailed Product Description

Material:	Manganese Steel	Loading Capacity:	1000kg
Platform Height:	6m	Working Height:	8m
Platform Size:	1800*1000mm	Lifting Power:	2.2kw
Weight:	1100kg	Measurement:	200012001450mm
High Light:	mobile hydraulic lift , hydraulic working platform

6 Meters Industrial Hydraulic Lift Platform Scissor Lift Aerial Work Platform 1 Ton Load

Major Parameters

Loading Capacity			1000kg
Maximum Height			6000mm
Minimum Height			1450mm
Platform Size			1800*1000mm
Lifting Power			2.2kw
Power Voltage			1phase/220V/50HZ or 3phases/380V/50HZ
Lifting Time			60s
Cylinder			Ф100(2Pcs)
Gear Pump			6ml/r
Total Weight			1100kg
Measurement			200012001450mm

Description

Mobile Scissor Lift Platform is an ecnomic lifting equipment with large loading capacity and good adapbility.

People can push it to everywhere they need. With outriggers to adjust the horizontal level of the machine and give support to prevent falling.

It is prohibited to over load the mobile scissor lift, first it will make the scissor arm distortion and the machine may fall to the ground. The fence on the platform is detachable to let the machine pass the low height space and easy storage.

Model List

Model	MK600	MK750	MK900	MK1100	MK1200
Load	500Kg	500Kg	500Kg	500Kg	500Kg
Platform Height	6m	7.5m	9m	11m	12m
Working Height	8m	9.5m	11m	13m	14m
Platform Size	1.85*0.88m	1.8*1.00m	1.8*1.00m	2.1*1.15m	2.45*1.35m
Lifting time	54S	72S	80S	88S	90S
Motor Power	1.5Kw	1.5Kw	1.5Kw	2.2Kw	3Kw

Model	MK1400	MK1600	MK600T	MK900T	MK1200T
Load	500Kg	300Kg	1000Kg	1000Kg	1000Kg
Platform Height	14m	16m	6m	9m	12m
Working Height	16m	18m	8m	11m	14m
Platform Size	2.45*1.35m	2.75*1.5m	1.8*1.00m	1.8*1.25m	2.45*1.35m
Lifting time	120S	130S	80S	100S	135S
Motor Power	3Kw	3Kw	2.2Kw	3Kw	4Kw

A1: Standard Configuration for Manual Pushing Around Scissor Lift
1. AC power : 220V 50Hz/60Hz, single phase or 380V 50Hz/60Hz, three phases
2. Rain-proof electric cabinet
3. Beacon light
4. Inflated Tyre
5. Forklift slot
6. Towing hook
7. Chinese domestic brand hydraulic power pack
8. Pressure gauge
9. Auxiliary release valve
10. Level gauge
11. Emergency stop button both on platform and ground
12. Key lock power switch
13. Lockable stabilizer
14. Anti-skid floor on platform with removable handrails
15. Toe protection boards on the platform
16. Operation voltage at 24V
17. Ladders for access to the stowed platform (Ladder for easy accessibility)
18. Limit switch provided for top motor shut off
19. Removable control box on platform
20. Interlock doors on platform
21. Detachable / Fold-able Fence
22. Powder coating painting
23. Spring mounted handles
24. Nylon bush assembled in between each scissor
25. Short Circuit and leakage protection system

A2: Optional Configuration for Manual Pushing Around Scissor Lift
1. Platform extension
2. Overloading protection
3. DC power supply
4. Battery Indicator for DC power
5. Hour meter for DC power
6. AC&DC power supply
7. Manual power
8. Motorized device for easily pulling
9. Horn available for motorized device
10. Explosion proof type
11. Maintenance supporting bar
12. Solid Tyre
13. Overseas brand hydraulic power pack
14. Outrigger sensor
15. Horn on the platform
16. AC power to the platform
