Heavy Duty Cargo Lift Table Cargo Elevator Scissor Lift Platform 3 Tons

Product Details:

Place of Origin:	China
Brand Name:	Bestmax
Certification:	CE
Model Number:	SJG 3-4.2

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Wrapped in pallet
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	100 sets/month

Contact Now

Detailed Product Description

Loading Capacity:	3000kg	Lifting Height:	4.20m
Lifting Power:	4kw	Lift Drive / Actuation:	Hydraulic
Lift Mechanism:	Scissor Lift	Keywords:	Cargo Lift
Highlight:	hydraulic cargo lift , cargo lifting equipment

Heavy Duty Cargo Lift Table Cargo Elevator Scissor Lift Platform 3 Tons

Description of Cargo Lift Table

Customary Multifunction Scissor Lift is the scissor lift with the function of elevating, rotating, side-upturning and clamping, meets all kinds of loading requirements.

Main Character of Cargo Lift Table
1. Easily installation and maintenance
2. The number of forks for the lift are different from one, two three or more, it depends on the size of the platform and the lifting height.
3. Excellent mechanical structure, it works in lower initial lifting height with maximum lifting stroke.
4. The antiskid design endows the platforms with excellent antiskid property
5. Fine grinding cylinder in good sealing performance
6. Equipped with safeguard valve to avoid hydraulic pipe rupture

Application of Cargo Lift Table

For different application purpose, the cargo lift table can be customized upon request, hereby below showing some customization cases
Fences can be added on the platform as required
The material is also by the manganese steel but stainless steel can also be used in meat processing factory for example
The table can be made to be round shape or make it to be tilting type, or with nipple on it or with roller on it.
The organ cover can also be made for the protection purpose

Major Parameter of Cargo Lift Table

To customize a stationary (fixed) scissor lift, below three major parameters have to be provided:

LOADING CAPACITY
PLATFORM SIZE
MAXIMUM HEIGHT (STOWED HEIGHT+ TRAVELLIGN HEIGHT)

Type	Model No.	Loading Capacity (T)	Stowed Height (mm)	Lift Height (mm)	Maximum Height (mm)	Platform Size (mm)	Lift Time (s)	Motor Power (Kw)	Weight (kg)
Single-Fork	SJG0.9-0.5	0.9	180	500	680	1220X700	15	0.75	400
	SJG2.65-1.2	2.65	230	1200	1430	1680X1000	39	3	650
	SJG3-1.2	3	240	1200	1440	1800X1800	40	3	1100
Double-Forks	SJG0.5-2.8	0.5	460	2800	3260	2200X1000	25	1.5	600
	SJG2.5-2	2.5	620	2000	2620	2200X1200	40	3	1300
	SJG5-1.5	5	460	1500	1960	1700X1000	50	4	1450
Multi-Forks	SJG1-4.1	1	913	4100	5013	2200X1000	39	3	1160
	SJG2-3.5	2	722	3500	4222	2100X1500	48	5.5	2100
	SJG3-7.2	3	1050	7200	8250	3400x1500	117	7.5	5500

Configurations:

Electric system:Schneider contactor, SANLICO button, CHNT electrical
Hydraulic System:Hycman brand power pack , sealing
Scissor Arm Support:Hi-strength Manganese steel rectangle tube Q345 B
Platform Surface:Antiskid checkered plate
High-pressure Oil Pip:Double wire hydraulic intensifier rubber hose

Optional Configuration:

Power Supply: 3phases/380V/50HZ; DC 24V; manual pump
Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher
Extension Platform
Flame Proof Control Cabinet
