| Place of Origin: | China |
| Brand Name: | CHEN LIFT |
| Certification: | CE ISO9001:2008 IPAF member |
| Model Number: | SEP2-4 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Packed with Pallet, Wrapped with Film |
| Delivery Time: | 30 days after order confirmed |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 100 sets/month |
| Max Platform Height: | 4m | Max Working Height: | 5.4m |
|---|---|---|---|
| Loading Capacity: | 200kg | Platform Size: | 600*640 Mm |
| Lifting Motor: | 12V/1.6kw | Overall Weight: | 380kg |
| High Light: | order picker platform,vertical order picker |
||
200kg Load 4m Lifting Height Warehouse Semi Electric Aerial Platform Order Picker
| Model | SEP2-2.7 | SEP2-3.3 | SEP2-4.0 | SEP2-4.5 |
| Loading Capacity | 200Kg | 200Kg | 200Kg | 200Kg |
| Max. Platform Height | 2.72m | 3.30m | 4.00m | 4.50m |
| Max. Machine Height | 4.02m | 4.90m | 5.40m | 6.10m |
| Platform Size | 600*640mm | 600*640mm | 600*640mm | 600*640mm |
| Stowed Length | 1.30m | 1.30m | 1.32m | 1.32m |
| Stowed Width | 0.85m | 0.85m | 0.85m | 0.85m |
| Stowed Height | 1.76m | 2.04m | 1.83m | 2.00m |
| Ground Clearance | 30mm | 30mm | 30mm | 30mm |
| Lift Motor | 12V/1.6Kw | 12V/1.6Kw | 12V/1.6Kw | 12V/1.6Kw |
| Battery | 12V/120Ah | 12V/120Ah | 12V/120Ah | 12V/120Ah |
| Charger | 12V/15A | 12V/15A | 12V/15A | 12V/15A |
| Overall Weight | 270Kg | 320Kg | 380Kg | 420Kg |
Semi-electric aerial order picker is with high safety, moving easily and convenient working. This product is broadly accepted by our clients due to their superior finish, durability, high load bearing capacity and longer service life without any hassles. Offered in various technical specifications, this range of order picker is available at the most reasonable prices.
Operation of Picker
