Double Mast Mobile Vertical Lifting Platform Aerial Work Platform

Basic Information
Place of Origin: China
Brand Name: CHENLIFT
Certification: CE
Model Number: ME
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wrapped in pallet or in wooden case
Delivery Time: 30day after down payment
Payment Terms: T/T L/C
Supply Ability: 200 sets per month
Detail Information
Highlight:

hydraulic drum lifter

,

oil drum lifting equipment


Product Description

Double Mast Mobile Vertical Lifting Platform​


Major Parameter of Single Mast Aluminum Aerial Work Platform

Model NO. Working Height (m) Loading Capacity (Kg) Platform
Size (m)
Lifting
Power (Kw)
Weight
(Kg)
Dimension (m)
GTWY6-100 8 130 0.60x0.55 0.75 260 1.38x0.80x1.65
GTWY8-100 10 130 0.60x0.55 0.75 300 1.38x0.80x1.98
GTWY9-100 11 130 0.60x0.55 0.75 326 1.44x0.85x1.98
GTWY10-100 12 130 0.60x0.55 0.75 400 1.44x0.85x1.98


Major Parameters of Double Mast Aluminum Aerial Work Platform

Model NO. Working Height(m) Loading Capacity(Kg) Platform Size(m) Lifting Power (Kw) Weight(Kg) Dimension(m)
GTWY6-200 8 200 1.18x0.62 1.1 380 1.38x0.85x2.00
GTWY8-200 10 200 1.18x0.62 1.1 480 1.38x0.95x2.00
GTWY9-200 11 200 1.38x0.62 1.1 548 1.58x0.95x2.00
GTWY10-200 12 200 1.38x0.62 1.1 610 1.68x0.95x2.00
GTWY12-200 14 200 1.48x0.62 1.1 650 1.68x0.95x2.00
GTWY14-200 16 150 1.48x0.62 1.1 650 1.68x0.95x2.00



Description
By the mast quantity: single mast, double mast, triple mast, quadruple mast and six masts (four plus two) are ranked in the product range of man pushing around aerial work platform
Features non-marking tires and anodized aluminum mast. Easily pushed around to the designated sites, beautiful structure, compact main body, light weighted, safe and reliable. It is operated by the telescopic cylinder which is strong and reliable working and the control panels are available on the lift platforms and ground.


Application
It is mainly used for the installation and maintenance of the narrow spaces such as star hotels, modern workshops, business hall, hotels, lobby, restaurant, railway stations, exhibition hall and shopping malls, it is a good helper for the equipment maintenance, paint decoration; Easily going through the regular doors and elevators, of low energy consumption, no pollution, no damage to the grounds.


Main Configurations of Man Pushing Around Aluminum Aerial Work Platform

Double Mast Mobile Vertical Lifting Platform Aerial Work Platform 0
Double Mast Mobile Vertical Lifting Platform Aerial Work Platform 1
Company Introduction
Chenlift (Suzhou) Machinery Co Ltd. Is a suzhou-based world-wide supplier of lifting equipment with over 20 years of experience in the lifting industry, we have the knowledge to assist you in acquiring your next lifting equipment.


Customer Visiting


Double Mast Mobile Vertical Lifting Platform Aerial Work Platform 2

Why choose Our Mobile Vertical Lift?
· High Quality
· Reasonable Price
· Good after Service
· 1 Year Warranty
· More Than 20 Years Experience
