Name: MOP300 Full Electric Order Picker
Brand: CHENLIFT (SUZHOU) MACHINERY CO LTD
SKU: MOP300
Price: 6,850.00 USD
Availability: InStock

Detail Information

Highlight:

drum lifter forklift attachment

hydraulic drum lifter

Product Description

Product Description:

Standard Configuration

※Electric Picking Tray and Front Guard Rails

※Self-locking Gates

※Drivable at Full Height

※Non-Marking Tires(Two-Wheel Drive Two-Wheel Steering)

※Emergency Descent System

※Emergency Stop Button

※Saloon-door Style Entry Gates / Top Open Door

※Flashing Beacon

※Charging Indicator

※Manual Brake Release

※Lanyard Attachment Point

※Tie-Down and Lifting Points

※Charging Protection System

Optional Configurations

※AC Power to Platform

※Platform Working Light

※Wireless Tracking

MOP300 Full Electric Order Picker 0

Manufacturer	CHENLIFT
Model designation	MOP300
Drive unit	Electric
Operator type	Order-picker
Rated capacity	90/110/136kg
Wheelbase	1095mm
Serice weight	800kg
Axle loading,laden front/rear	590/410kg
Axle loading,unladen front/rear	380/420kg
Tyre type	Polyurethane/Solid rubber
Tyre size,front	Φ210x70mm
Tyre size,rear	Φ250x100mm
Additional wheels	Φ74X48mm
Wheels,number front/rear(x=drive wheels)	1×,212mm
Tread,front	545mm
Tread,rear	640mm
Height,mast lowered	1365mm
Free lift	485mm
Lift height	3485mm
Height,mast extended	4365mm
Height of overhead/guard cabin	1410mm
Seat height/standing height	285mm
Stand height,elevated	3000mm
Overall length	1440mm
Overall width	750mm
Ground clearance,center of wheelbase	35mm
Turning radius	1260mm
Travel speed,laden/unladen	6/6.5km/h
Lifting speed,laden/unladen	0.038/0.40m/s
Lowering speed,laden/unladen	0.040/0.038m/s
Max.gradeability,laden/unladen	5/8%
Serice brake	Electromagnetic
Drive motor rating S2 60 min	0.65KW
Lift motor rating at $315%	2.2KW
Battery voltage/nominal capacity	24/120V/Ah
Battery weight	71kg
Type of drive unitS	DC
teering design	Electronic
Sound pressure level at the driver's eal	60dB(A)

Company Introduction:

Chenlift (Suzhou) Machinery Co Ltd. is a suzhou-based world-wide supplier of lifting equipment with over 20 years of experience in the lifting industry, we have the knowledge to assist you in acquiring your next lifting equipment.

Tag:

Place of Origin:	China
Brand Name:	CHENLIFT
Certification:	CE
Model Number:	MOP300

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Wrapped in pallet or in wooden case
Delivery Time:	30day after down payment
Payment Terms:	T/T L/C
Supply Ability:	200 sets per month
