Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform

Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform

  • Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform
  • Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform
Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform
Product Details:
Place of Origin: China
Brand Name: CHEN LIFT
Certification: CE
Model Number: GTWY12-200 (ME1200-2)
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallet or in wooden case
Delivery Time: 30day after down payment
Payment Terms: T/T
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Loading Capacity: 200kg Platform Height: 12m
Working Height: 14m Platform Size: 1.52*0.62m
Extension Platform Length: 0.8m Extension Platform Loading Capacity: 100kg
Motor Power: 1.10Kw Overall Size: 1.76*1.00*2.00m
Weight: 830kg
High Light:

mobile aerial work platform

,

hydraulic aerial work platform



Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform





Quick Detail:



Name Mobile Aerial Work Platform Brand Name CHEN LIFT
Loading Capacity 200Kg Platform Height 12m
Platform Size 1.52*0.62m Color Optional
Motor Power 1.10Kw Power Supply AC/DC
Extension Platform Length 0.8m Extension Platform Loading Capacity 100Kg





Descriptions



Mobile aluminum aerial work platform with Extension Platform, compared with mast aluminum AWP, it is equipped with the Extension Platform, which can extend 0.8m on one side. This design can enlarge the platform working area, reach farther place and then improve the working efficency.





Applications:



It is mainly used for the installation and maintenance of the narrow spaces such as star hotels, modern workshops, business hall, hotels, lobby, restaurant, railway stations, exhibition hall and shopping malls, it is a good helper for the equipment maintenance, paint decoration; Easily going through the regular doors and elevators, of low energy consumption, no pollution, no damage to the grounds. The lifting height ranges from 6m to 12m and lifting capacity varies from 200kg to 250kg.The power sources could be 220V, 380V or chargeable battery.





Main Features:



1. Most rigid aluminum alloy profile

2. Auxiliary platform lowering

3. Multi-guide pulley on mast

4. Durable base system

5. Chassis with level gauge

6. DC working power on the platform

7. Easily rolls through a narrow space

8. Emergency stop button

9. Over load protection

10. Built-in pressure release valve

11. Dual activated up/down switch

12. Locking Key Switch





Specifications:



MODEL GTWY12-200 (ME1200-2)
PRODUCTIVITY US Metric
Lift capacity 441lbs 200kg
Working height 45ft 11.18in 14m
Platform floor height 39ft 4.44in 12m
Platform length 4ft 11.84in 1.52m
Platform width 2ft 0.41in 0.62m
Ground Clearance 1.97in 0.05m
Lifting Power 1.1kw
Lifting Speed 0.09-0.1m/s
Motorized Power 0.75Kw
Descending Speed 0.08m/s
Anti Wind Capacity Max. force 5
Overall length 5ft 9.29in 1.76m
Overall width 3ft 3.37in 1.00m
Overall height 6ft 6.74in 2.00m
Outrigger footprint:
A Length 6ft 10.68in 2.10m
B Width 6ft 6.74in 2.00m
C Corner access 3.94in 0.10m
D Wall access front 1ft 0.59in 0.32m
E Wall access side 2ft 1.59in 0.65m
Weight 1830lbs 830kg

Lifting Heihght 12m Mobile Aluminum Aerial Work Platform with Extension Platform 0

Optional Configuration:

  • Power Supply: 3phases/380V/50HZ; DC 24V
  • Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher
  • Extension Platform
  • Flame proof electric cabinet



Competitive Advantage:



· High Quality

· Reasonable Price

· Good after Service

· 1 Year Warranty

· More Than 10 Years Experience
