Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters

Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters

  • Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters
  • Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters
  • Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters
Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters
Product Details:
Place of Origin: Original from China
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: MG750-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 days after receipt of deposit
Supply Ability: 100 set/ month
Contact Now
Detailed Product Description
Model: MG750-2 Lift Capacity: 200kg
Platform Height: 7.5m Platform Size: 1.00*0.70m
Power Source: 2*12V/120Ah Charger: 24V/12A
Weight: 1100kg Color: Customizable
High Light:

mobile aerial work platform

,

hydraulic aerial work platform



Self-propelled Aerial Work Platform Safety For Work At Height 7.5 Meters High With 2 Masts



Machine Parameter:

Model MG750-2
Lift capacity 200kg
Platform height max 7.5m
Stowed length 1.5m
Stowed width 1.0m
Stowed height 1.99m
Platform size 1.00*0.70m
Ground clearance 0.05m
Wheelbase 1.28m
Grade ability 25%
Maximum working slope
Driving wheel φ0.25*0.08m
Front tire 8in
Driving motor 2*24V/0.5kw
Lifting motor 24V/2kw
Power source 2*12V/120Ah
Charger 24V/12A
Weight 1100kg


Standard Configurations:

Proportional Control

Power Supply

Traceless Tyre

4*2 Driving

Automatic Brake System

Auxiliary Lowering System

Emergency Stop System

Anti-burst System

Tilting Protection System

Buzzer

Horn

Fork Lift Slots

Charging Protection System



Optional Configurations:

AC Power to Platform

Platform Working Light

Extension Platform



Self-propelled Aerial Work Platform Safety Vertical Lift Table With 2 Masts 7.5 Meters 0







Why choose Chen lift Self-Propelled Aluminum Aerial Work Platform?
· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· One year warranty



Communication with Customers
A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?
B: The main difference is from the structure and the material
The scissor lift is in scissor structure with steel material
The aerial work platform is in mast structure with aluminum material

A: How is that for quality control in your factory?
B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly

  • Strict quality control system on the whole process of production
  • Imported key arts to ensure the high quality of our products
  • Advanced equipment and tools for examination and quality control
  • 100% strict examining products before shipment
  • All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.



A: What is the delivery time for your goods?
B: 30 days, after order confirmation
