Self Propelled Aerial Work Platform Double Mast 9 Meters High Manlift In Red 150Kg Loading Capacity

Basic Information
Place of Origin: Original from China
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: MG900-2
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 days after receipt of deposit
Supply Ability: 100 set/ month
Detail Information
Model: MG900-2 Lift Capacity: 150Kg
Platform Height: 9m Platform Size: 1.00*0.70m
Working Height: 11m Charger: 24V/12A
Weight: 1250Kg Color: Customized
Highlight:

mobile aerial work platform

,

hydraulic aerial work platform


Product Description



Self Propelled Aerial Work Platform Double Mast Manlift In Red 150Kg Loading Capacity



Machine Parameter:

Model MG900-2
Lift capacity 150Kg
Platform height max 9m
Stowed length 1.5m
Stowed width 1.0m
Stowed height 1.99m
Platform size 1.00*0.70m
Ground clearance 0.05m
Wheelbase 1.28m
Grade ability 25%
Maximum working slope
Driving wheel φ0.25*0.08m
Front tire 8in
Driving motor 2*24V/0.5kw
Lifting motor 24V/2kw
Power source 2ˣ12V/120Ah
Charger 24V/12A
Weight 1250Kg



Self Propelled Aerial Work Platform Double Mast 9 Meters High Manlift In Red 150Kg Loading Capacity 0



Self Propelled Aerial Work Platform Double Mast 9 Meters High Manlift In Red 150Kg Loading Capacity 1



Standard Configurations:

Proportional Control

Power Supply

Traceless Tyre

4*2 Driving

Automatic Brake System

Auxiliary Lowering System

Emergency Stop System

Anti-burst System

Tilting Protection System

Buzzer

Horn

Fork Lift Slots

Charging Protection System



Optional Configurations

AC Power to Platform

Platform Working Light

Extension Platform
