Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity

Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity

  • Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
  • Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
  • Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
  • Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
  • Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity
Product Details:
Place of Origin: Original of China
Brand Name: BestMax
Certification: CE ISO9001:2008 IPAF member
Model Number: MX1000S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallets/ wooden case
Delivery Time: 30 day after receipt of deposit
Payment Terms: T/T, L/C
Supply Ability: 100 sets/ month
Contact Now
Detailed Product Description
Model: MX1000S Loading: 320kg
Platform Size: 2.27*1.12m Measurement: 2.43*1.15*1.91m
Battery: 4*6V/240Ah Total Weight: 2468kg
Color: Green, Customized Color Is Available Platform Height: 10m
Working Height: 12m Extension Platform: 0.9m
Extension Loading: 113kg Gradeability: 25%
High Light:

self propelled work platform

,

self propelled lift

4 x 2 Driving Self Propelled Scissor Lift 2.43m * 1.15m * 1.91m with 10m Platfprm Height



Description:



Bestmax Self-propelled Electric Scissor Lift  has simple structure, smooth driving, fater speed, lower noise, deeply loved by users who always work outdoor. to provide you with a flexible mobility, operability. It is unique in carrying capacity and wide platform that can bring more workers and tool set. Whether indoors and outdoors it can be used. It can greatly improve the working efficiency to assist finish various aerial work tasks in different situations as it can travel in any status whether lifted or stowed. Smart, flexible, quick, it can be operated by one single to control on the platform and no human power needed to move it.



Parameters



Model

MX1000S

Load capacity

320kg

Extension load capacity

113kg

Max Worker number

2

Working height

12m

Platform floor height

10m

Measurement

2.43*1.15*1.91m

Extension platform size

2.27*1.12m

Ground clearance(stowed)

0.1m

Ground clearance(raised)

0.019m

Wheel base 1.87m

Turning Radius(inside)

0m

Turning Radius(outside)

2.2m

Lifting / drive motor 24V/3.3kw
Travelling speed(stowed) 3.0km/h
Travelling speed(raised) 1.0km/h
Lifting/ lowering speed

60/40sec

Batteries 4*6V/240Ah
Charger 24V/ 30A
Gradeability 25%
Max working slop 2°/3°
Tyre Ф380*129
Weight 2468kg



Flexible Operation



Fully proportional control, either lifting or moving, all can easily operating in the joystick. Zero inside turning radius, allowing users to use in a narrow space, and also facilitate changing positions. It has two kinds of moving speed to secure move quickly and lift safe.



Easy Maintenance



It give full consideration to the convenience of the user in their daily work. It has fault diagnosis system help the user can find the failure point one time. And also reduce the losses caused by forgotten maintenance.



Platform Swing Gate



Platform Swing Gate make enter and out space more large, no restrictions to the guardrails.

Fold-able guardrail make the machine can be easily through standard doors when move during working area.



Airway tube to platform



User can be optional airway tube to platform to make sure pneumatic tools and equipment can be used in the platform



AC wiring to platform



AC wiring and socket to platform to meet the customers demand to make sure the electric tools can be used in the platform.



Key-type lock sliding



Key-type lock sliding door to protect misuse by not equipment keeper, particularly suitable for protect the electrical components when the rent out



Platform work light (optional)



The professional platform work lights allows construction of the user easier lighting and operating



Motion alarm and Horn



The machine is equipped with motion alarm and horn when moving to remind around person to take necessary precaution.



Standard Configuration:



Proportional control                             Auto-brake system

Auto-lock door on platform                  Extension Platform

Drivable when lifted                             Traceless tire

4 x 2 Driving                                        Auxiliary lowering device

Emergency stop button                       Horn

Fault diagnosis system                       Tilting protection system

Action buzzer                                      Time Recorder

Supporting bar                                    Fork Lift Slot

Charging protection system                Strobe light

Detachable fence                                Automatic pothole protection



Optional Configuration:

  • Overload protection sensor with alarm
  • DC Power connection to the platform
  • Working light on the platform
  • Airway tube to the platform



Factory Sale Electric Self Propelled Scissor Lift Table 10m Platform Height 320kg Loading capacity 0



Why choose Bestmax Self Propelled Scissor Lift?


· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· One year warranty



Thank you for your reading and welcome your inquiry. We will respond you as soon as possible.
