Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type

Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type

    • Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type
    • Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type
    • Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type
  • Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type

    Product Details:

    Place of Origin: China
    Brand Name: Xunte
    Model Number: DT500

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Wrapped in pallet or in wooden case
    Delivery Time: 30day after down payment
    Payment Terms: T/T L/C
    Supply Ability: 200 sets per month
    Contact Now
    Detailed Product Description

    Electric Drum Stacker with 500Kg Load And 1.6m Lifting Height Eagle-gripper Type





    Quick Detail:



    Name Electric Drum Lift Brand Name Xunte
    Loading Capacity 500Kg Color Yellow
    Lifting Height 1600mm
    Lifting Speed 120mm/s
    Power Supply DC





    Description:



    The Electric Drum Stacker has simple and light-weight structure; the eagle-gripper type structure design is quite suitable for loading steel and plastic drums. The operation of the drum stacker is simple and labor-saving. It is used for the transporting, loading and unloading liquid like dyes, paintings, adhesive, oil and so on. In general, the Electric Drum Lift can provide you with safe and easy transportation of drums.





    Main Features:

    • Use high-quality hydraulic pump unit which can provide strong driving force and long-lasting and maintenance-free battery.

    • The gantry is made up of special-rolled industrial-manufactured C-type steel which is strong and safe.

    • High-quality oil cylinder with fast lifting speed and the lifting height can reach 1600mm. The drum lift can electrical tilt 180°.

    • With electronic balance which has functions like resting to zero, taring and weighting. The accuracy of the electronic balance can reach ±3‰.



    Major Parameters



           Model:                                                    DT500

    • Loading Capacity                                    500kg

    • Net Weight                                              208Kg

    • Wheel Dimension                                   Φ80*55,Φ150*50

    • Inner/Outer Width of Front Leg(mm)      640/800

    • Outline Dimension(mm)                         1200*850*2060

    • Turning Radius (mm)                             1400

    • Pump Unit Power (Kw/h)                        1.5

    • Battery Parameter (Ah/V)                       120/12

    • Lifting Height (mm)                                 1600

    • Lifting Speed (mm/s)                               120



    Why to choose Xunte Electrical Drum Lift?

    • High Quality

    • Reasonable Price

    • Good after Service

    • 1 Year Warranty

    • More Than 10 Years Experience
