Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall

Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall

    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
    • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall
  • Hydraulic Manual Material Lift for Hotel / Restaurant / Hotel Exhibition Hall

    Product Details:

    Place of Origin: China
    Brand Name: Xunte
    Certification: CE
    Model Number: SLA-15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $10000-$1500
    Packaging Details: Wrapped in pallets
    Delivery Time: 30 days
    Payment Terms: T/T L/C
    Supply Ability: 100 sets/month
    Contact Now
    Detailed Product Description
    Lifting Height-“up”: 5m Lifting Height-“down”: 4.48m
    Load At 46cm: 363kg Load At 61cm: 363kg
    Load At 1.07m: 227kg Weight: 183kg



    Hydraulic Manual Material Lift for Hotel / Resturant / Hotel Exhibition Hall





    Quick Detail:



    Name Manual Material Lift Brand Name Xunte
    Lifting Height-“up” 5.00m Lifting Height –“down” 4.48m
    Load at 46cm 363kg Load at 61cm 363kg
    Load at 1.07m 227kg Power Manual one speed winch
    Color Blue or Optional





    Description:



    Manually operated material lift with multiple base, winch and load handling options to create just the lift you need. The compact, portable design rolls through standard single doorways and it is easy for one person to set up, operate and transport in a standard pickup or service truck. Maneuverable front casters and rear casters with swivel locks. Plus, a wide variety of options and accessories make them extremely adaptable to fit your specific needs.





    Main Features:



    1. Manually operated with multiple base, winch and load handling options

    2. Compact, portable design

    3. Easily rolls through standard single doorways

    4. It is easy for one person to set up, operate and transport in a standard pickup or service truck.

    5. Maneuverable front casters and rear casters with swivel locks.

    6. A wide variety of options and accessories make them extremely adaptable to fit specific needs.





    Major Parameters



    Model SLA-15
    Working height
    standard forks-up 5.00m
    standard forks-down 4.48m
    Adjustable forks-up 5.00m
    Adjustable forks-down 4.48m
    Flat forks 4.48m
    Boom*** 4.76m
    Load platform**-forks up 4.98m
    Load platform**-forks down 4.46m
    Height-stowed 1.98m
    Length-stowed 0.75m
    Length-operating 2.2m
    Width-stowed 0.79m
    —stabilizers lowered 1.9m
    Width-straddle base*
    Minimum 0.80m
    Maximum 1.47m
    Maximum inside 1.27m
    Ground clearance-center 0.05m
    Load height minimum 0.15m
    Productivity
    Load capacity
    46cm load center 363kg
    61cm load center 363kg
    1.07m load center 227kg
    Power
    Power Single speed winch
    Weight
    Standard 183kg





    Applications:



    Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.
