10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift

10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift

    • 10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift
    • 10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift
    • 10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift
    • 10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift
  • 10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift

    Product Details:

    Place of Origin: China
    Brand Name: Bestmax
    Certification: CE
    Model Number: GTWY10-200 (ME1000-2)

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Wrapped in pallet or in wooden case
    Delivery Time: 30 days after down payment
    Payment Terms: T/T, L/C
    Supply Ability: 200 sets per month
    Contact Now
    Detailed Product Description
    Lift Capacity: 200Kg Platform Height: 10m
    Working Height: 12m Platform Size: 1.52*0.62m
    Overall Size: 1.76*1.00*2.00m Lifting Motor: 1.1Kw
    Keywords: Aluminum Man Lift Application: Aerial Work





    10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift



    Specifications:



    Name Aluminum Aerial Work Platform Brand Name Bestmax
    Loading Capacity 200Kg Platform Height 10m
    Platform Size 1.52*0.62m Color Yellow or Optional
    Motor Power 1.10Kw Power Supply AC/DC



    Descriptions:



    By the mast quantity: single mast, double mast, triple mast, quadruple mast and six masts (four plus two) are ranked in the product range of man pushing around aerial work platform.
    Features non-marking tires and anodized aluminum mast. Easily pushed around to the designated sites, beautiful structure, compact main body, light weighted, safe and reliable. It is operated by the telescopic cylinder which is strong and reliable working and the control panels are available on the lift platforms and ground.



    Applications:



    It is mainly used for the installation and maintenance of the narrow spaces such as star hotels, modern workshops, business hall, hotels, lobby, restaurant, railway stations, exhibition hall and shopping malls, it is a good helper for the equipment maintenance, paint decoration; Easily going through the regular doors and elevators, of low energy consumption, no pollution, no damage to the grounds. The lifting height ranges from 6m to 12m and lifting capacity varies from 200kg to 250kg.The power sources could be 220V, 380V or chargeable battery.



    Main Features:



    1. Most rigid aluminum alloy profile

    2. Auxiliary platform lowering

    3. Multi-guide pulley on mast

    4. Durable base system

    5. Chassis with level gauge

    6. DC working power on the platform

    7. Easily rolls through a narrow space

    8. Emergency stop button

    9. Over load protection

    10 .Built-in pressure release valve

    11. Dual activated up/down switch

    12. Locking Key Switch

    13. Optional extended platform

    14. Entry ladder



    Optional Configuration:

    • Power Supply: 3phases/380V/50HZ; DC 24V
    • Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher
    • Extension Platform
    • Flame proof electric cabinet

    10 Meters Aluminum Aerial Work Platform Double Mast Vertical Lift



    Communication with Customers



    A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?

    B: The main difference is from the structure and the material

    The scissor lift is in scissor structure with steel material

    The aerial work platform is in mast structure with aluminum material



    A: How is that for quality control in your factory?

    B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly

    1. Strict quality control system on the whole process of production
    2. Imported key arts to ensure the high quality of our products
    3. Advanced equipment and tools for examination and quality control
    4. 100% strict examining products before shipment
    5. All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.
