Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height

Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height

    • Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height
    • Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height
    • Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height
  • Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height

    Product Details:

    Place of Origin: China
    Brand Name: Bestmax
    Certification: CE ISO9001:2008 IPAF member
    Model Number: MX1200S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiable
    Packaging Details: Wrapped in pallets/ wooden case
    Delivery Time: 30 days after receipt of deposit
    Payment Terms: T/T L/C
    Supply Ability: 100 sets/month
    Contact Now
    Detailed Product Description
    Model: MX1200S Loading Capacity: 320kg
    Platform Height: 11.8m Platform Size: 2.27*1.12m
    Extension Platform Length: 0.9m Extension Platform Lift Capacity: 113kg
    Weight: 2830kg Color: Customized Color Is Available
    Overall Size: 2.43*1.15*2.03m Power Source: 4*6V/260Ah





    Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.80m Working Height​


    Description:

    Self-propelled scissor lifts are also called as Electric Scissor lifts or electric elevated work platform; they are used to provide temporary access for contractors to high, inaccessible areas on a variety of job sites such as maintenance and construction work. They are designed to lift limited weights and capable of being fully operated by a single person. It is unique in carrying capacity and a wide platform that can bring more workers and tool set, whether indoors or outdoors.



    Main Features:


    1. Roll-out extension platform provide more workspace.

    2. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.

    3. Different models are available with the maximum working height at 6m to 16m

    4. Zero-turn radius and compact design provide access in and around confined work areas.

    5. 25% grade ability when driving on slopes.

    6. On-board diagnostic help operators troubleshoot on the fly and make adjustments in the field to maximize uptime

    7. Single extension platform provide more workspace.

    8. Manganese steel lifting arm in high strength with rectangle shape

    9. The anti-skid design endows the platforms with excellent anti-skid property

    10. The control panels are available on the platforms and ground.

    11. Fine grinding cylinder in good sealing performance

    12. Equipped with safeguard valve to avoid hydraulic pipe rupture

    13. Swing-out tray for easy maintenance access



    Specification:



    Model MX1200S
    Working height max (m) 13.80
    Platform height max (m) 11.80
    Slide-out platform extention deck (m) 0.90
    Lift capacity (kg) 320
    Lift capacity (kg) (Platform extended) 113
    Weight (kg) CE / AUS Standard 2830
    Platform size (L×W) (m) 2.27*1.12
    Platform length extended (m) 3.17
    Stowed size (L×W) (m) 2.43*1.15
    Stowed height (m) 2.55
    Hydraulic system capacity (L) 20
    Gradeability 0.25
    Ground clearance (m) 0.1
    Ground clearance (m) (pothole guards deployed) 0.019
    Platform occupancy max 2
    Raise / Lower time (s) 70/45
    Maximum Working Slope 1.5°/3°
    Lifting Motor Power 4.5Kw
    Power source 4×6V/260Ah
    Tire size (mm) Ф380*129




    Configurations:

    • Standard detachable platform
    • Extended platform
    • Proportional controls for lift and drive functions
    • Automatic 25Amp battery charger provides strong power for vehicle
    • Safe distance protection when the platform lowering down
    • Manual emergency platform lowing valve. When there is no power the machine can lower down safely.
    • Emergency stops are at both platform and ground control boxes.
    • Drive speed interlock limits speed while elevated
    • Multiple disc brakes provide smooth deceleration
    • When there is no power manual brake release function can move the machine under the circumstance when there is no other forklift, lifting equipment and so on.
    • Pothole guards protect the machine from tilting down when the machine moving on the raised position
    • Non-marking tires make sure there is no damage and no marks on the ground
    • AC wiring to platform
    • Tilt level sensor with audible alarm
    • Beeper horn
    • Hour meter
    • Safety brackets
    • Battery charge indicator
    • Forklift sockets
    • Diagnosis system
    • Fault code display


    Optional Configuration:

    • Fold-able guardrail
    • Motion alarm
    • Platform swing gate
    • Air line to platform
    • Dual flashing beacon
    • Maintenance-free battery
    • Horn
    • Platform work lights
    • Key-type lock sliding door
    • Anti-collision system
    • Head protection stop system


    Applications:

    1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.
    2. Aerial Working Purpose: machine maintenance, painting, cleaning etc


    Electric Aerial Work Platform Lift Capacity 320kg Self-propelled Scissor Lift of Max 13.8m Working Height


    Why to choose Bestmax Self-propelled Scissor Lift?

    • Much quieter

    All Best MX-series adopt high-performance battery power, pollution-free and no emissions, low noise electric pump, can also be used even in the area of high environmental requirements, such as office buildings, hotel, hospital, school and so on.


    • Flexible Operation

    Fully proportional joystick control, either lifting or moving, all can easily operate in the joystick.
    Zero inside turning radius allowing users to use in a narrow space, and also facilitate changing positions. MX-series has two kinds of moving speed to secure move quickly and lift safely. All the MX-series scissor lifts have extended platforms which makes the operator get close to the work points much easier and breakthrough the space obstacles.


    • Easy maintenance

    Best MX-series give full consideration to the convenience of the users in their daily work maintenance. All the Bestmax Electric Self-propelled Scissor Lifts have fault diagnosis system, this makes the user can find the point of failure in one time. Door-open control box and battery box allow maintenance person to find the maintenance point quickly and easily. Also it is easier to change the spare parts. The scissor booms repair bracket, so that the user dose not need the help of lifting equipment, boom system can be easily overhaul.
