Home ProductsAerial Work Platform

Mobile Dual Mast Vertical Access Platform

China CHENLIFT (SUZHOU) MACHINERY CO LTD certification
China CHENLIFT (SUZHOU) MACHINERY CO LTD certification
Marc was pleasantly surpriced about the excellent quality. There has been thought about everything: Engineering picobello, packing (not unimportent) s

—— Koen and Marc Sas

The manuevability of power lift is amazing. We can use it in tight space one day indoors and the next day rull it out on the turf.

—— Jan Aaris

No other AWP at the same price performed as well as it.

—— Koren White

I'm Online Chat Now

Mobile Dual Mast Vertical Access Platform

Mobile Dual Mast Vertical Access Platform
Mobile Dual Mast Vertical Access Platform

Large Image :  Mobile Dual Mast Vertical Access Platform

Product Details:

Place of Origin: Original of China
Brand Name: CHEN LIFT
Certification: ISO, CE
Model Number: GTWY 12-200

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wrapped in pallet or in wooden case
Delivery Time: 30 days after order confirmed
Payment Terms: T/T or L/C
Supply Ability: 200 sets per month
Detailed Product Description
Model: GTWY 12-200 Material: Aluminum Alloy
Color: Blue Or Customized Maximum Platform Height: 12m
Platform Size: 1.58*0.62 M Rated Load: 200 KG
Max Working Height: 14 M Mast: Double
Standard Power: AC Power Weight: 830 Kg
High Light:

hydraulic aerial work platform

,

aerial work platform



Mobile Dual Mast Vertical Access Platform Aerial Work Platform Aluminum Lift

Description



It is very light and easy to be operated by single person with control panels on platform and ground. With high quality and excellent performance, the lift provides a reliable method for lifting people and tools or goods up for various tasks, doing maintenance work, construction or emergency access for firefighters.



Parameters



Model

GTWY12-200

Platform Height

12m

Load Capacity

200KG

Platform size

1.52 x 0.62m

Ground Clearance

0.05m

Lifting power

1.1KW

Lifting speed

0.09-0.1m/s

Descending speed

0.08m/s

Anti-wind capacity

Max. force 5

Overall dimension

1.76 x1 x2 m



Features:

  • Most rigid aluminum alloy profile
  • Auxiliary Platform Lowering
  • Multi-guide pulley on mast
  • Durable base system
  • Chassis with level gauge
  • DC working power on the platform
  • Easily rolls through a narrow space
  • Emergency stop button
  • Over load protection
  • Built-in pressure release valve
  • Dual activated up/down switch
  • Locking Key Switch
  • The limit switch system helps to stop at accurate position.



Platform Control Box

It is built in the platform, this design can protect the buttons from rain and makes the appearance of the machine concise for all the lines are placed in the profile of the platform



Safety double chain

To ensure the safety of the operator, even on brake the other also can work



Outriggers Locking Pin

When you need to open the outrigger, pull it and place the outriggers to the place you want and then release it. It can protect the outrigger from moving while using the machine



Auxiliary Lowering System

When the power shut down, press it to descend the machine.



Ground Control Box

Have Emergency Stop on it to assure the safty of the whole machine and user.

And also equipped with transfer swith to choose platform control or ground control.



Level Gauge

It is place on the chassis to view the horizontal situation of the machine, only the bubble in the middle of the level gauge can the machine be used. With scale can help you adjust the horizon of the machine better.



Optional Configuration

  • Optional Power: AC380V DC24/48V,
  • Manual Hydraulic Power
  • Italian Brand Hydraulic Station
  • Explosion-Proof Electrical Sytem
  • Stainless Steel Fence



Mobile Dual Mast Vertical Access Platform 0

Mobile Dual Mast Vertical Access Platform 1



Why to choose CHEN LIFT Motorized Scissor Lift?
· High Quality product
· Reasonable Price
· Easy payment mode
· Timely delivery
· Good after Service
· Client-centric approach
· one year warranty

Thank you very much for your reading, welcome your inquiry. We will respond you as fast as we can.
