Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table

Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table

  • Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table
Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table
Product Details:
Place of Origin: China
Brand Name: CHENLIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: SJZ 1-9
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PVC Film Wrapped in Pallets or in wooden Case
Delivery Time: 30 days after order confirmed
Payment Terms: T/T or L/C
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Loading Capacity: 1000Kg Extension Length: 1000mm
Extension Loading: 100kg Platform Height: 9m
Working Height: 11m Platform Size: 1.80*1.25m
Lifting Power: 3Kw Motorized Power: 1.2Kw
Lifting Time: 108s Measurement: 1850*1490*1650mm
Weight: 1850kg
High Light:

mobile hydraulic lift

,

hydraulic aerial work platform



Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table with Motorized Device 1 Tons



Description:



Scissor lifts with Motorized Device and Extension Platform, it is driven by electricity which can save human force a lot while moving it. At the same time, the platform can be extended to reach farther space.



Main Features:



1. Pointing control of lifting up and down.

2. Manganese steel lifting arm in high strength with rectangle shape

3. Anti-skid floor in platform

4 The control panels are available on the platforms and ground.

5. Fine grinding cylinder in good sealing performance

6. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.



Safety Precaution:



1. The operation voltage on the platform is 24V

2. Emergency stop button on the platform and ground

3. Auxiliary platform lowering

4. Telescopic legs on the chassis

5. Hose burst valve safety

6. Rain-proof design electric cabinet

7. Fence on the platform



Major Parameters

  • Model: SJZ 1-9
  • Loading Capacity 1000kg
  • Maximum Height 9000mm
  • Platform Size 1800*1250mm
  • Lifting Power 3.0kw
  • Motorized Power: 1.2Kw
  • Lifting Time 108s
  • Gear Pump 6ml/r
  • Total Weight 1850kg
  • Measurement  1850*1490*1650mm



Configurations:

  • Electric system: Schneider contactor, SANLICO button, CHNT electrical
  • Hydraulic System: Hycman brand power pack , sealing
  • Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B
  • Platform Surface : Antiskid checkered plate
  • Tire: Ø400-8 Inflated tires
  • High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose :
  • Battery: (DC12V,150AH)*4 with charger



Optional Configuration:

  • Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher
  • Extension Platform
  • Rubber Solid Tire
  • Flame Proof Control Cabinet



Applications:



1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.

2. Aerial Working Purpose: machine maintenance, painting, cleaning etc.



Why choose Xunte Mobile Scissor Lift?



· High Quality

· Reasonable Price

· Good after Service

· 1 Year Warranty

· More Than 10 Years Experience





           Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table 0                             Electric Aerial Work Platform 9m Red Self Propelled Scissor Lift Table 1





Communication with Customers



A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?

B: The main difference is from the structure and the material

The scissor lift is in scissor structure with steel material

The aerial work platform is in mast structure with aluminum material



A: How is that for quality control in your factory?

B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly

1.Strict quality control system on the whole process of production

2.Imported key arts to ensure the high quality of our products

3.Advanced equipment and tools for examination and quality control

4.100% strict examining products before shipment

5.All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.



A: What is the delivery time for your goods?

B: it is 30days after order confirmation



A: What spare parts that you can offer?

B: We provide following spare parts freely for your maintenance of the machine:



Item Quantity
Fuse 3
"O" Rubber Seals Φ11 3
Wrench 1
Pressure Oiler 1
Cross Screwdriver 1
Straight Screwdrive 1



A: How long is your quality guarantee period?

B: We have one year warranty.
