Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation

Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation

  • Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation
  • Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation
Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation
Product Details:
Place of Origin: China
Brand Name: CHEN LIFT
Certification: CE
Model Number: MK300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PVC Film Wrapped in Pallets or Wooden Case
Delivery Time: 30 days after order confirmed
Payment Terms: L/C, T/T
Supply Ability: 100 sets/ month
Contact Now
Detailed Product Description
Loading Capacity: 240Kg Platform Height: 3m
Working Height (rails Up): 5m Platform Size: 1.15*0.7m
Motor Power: 0.8Kw Raise / Lower Time: 34s/20s
Weight: 482Kg Overall Size: 1.30*0.76*1.83m
High Light:

scissor lift mobile

,

mobile aerial work platform



Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation



Parameter:

Loading Capacity 240Kg
Platform Height 3000mm
Minimum Height (rails up) 1830mm
Minimum Height (rails down) 1430mm
Platform Size 1150mm*700mm
Ground Clearance​ 60mm
Motor Power 0.8kw
Power Voltage DC12V
Raise / Lower Time 34s / 20s
Total Weight 482kg
Overall Size 1300*760*1830mm



Description:

This mini scissor lift is easy to use. The control panels are available on the platforms and ground.
The user can control the machine walking and lifting operation directly on the platform, and realize the single person working continuously at high altitude.

Because it is miniature, the height is limited, suit low position aerial work. They are used to provide contractors with temporary access to high-altitude areas that are inaccessible to various workplaces, such as maintenance, construction projects or fire crews emergency access.

The scissor structure enables reliable stability when the lifts rising up, the broad platform and the high loading capacity get the aerial working more efficient and more safely.



Main Features:
1. Pointing control of lifting up and down.
2. Manganese steel lifting arm in high strength with rectangle shape
3. Anti skid floor in platform
4. The control panels are available on the platforms and ground.
5. Fine grinding cylinder in good sealing performance
6. Neatly folding guardrails
7. Battery and battery charger in bulit
8. Optional extension platform



Major Parameters

  • Model: MK300
  • Loading Capacity 240kg
  • Maximum Platform Height 3000mm
  • Maximum Working Height 5000mm
  • Minimum Height (rails up) 1830mm
  • Minimum Height (rails down) 1430mm
  • Platform Size 1150*700mm
  • Lifting Power 0.8Kw
  • Power Voltage DC12V
  • Raise / Lower Time 34s / 20s
  • Total Weight  482Kg
  • Overall Size 1300*760*1830mm



Configurations:

  • Electric system: Schneider contactor, SANLICO button, CHNT electrical
  • Hydraulic System: Hycman brand power pack , sealing
  • Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B
  • Platform Surface : Antiskid checkered plate
  • Tyre: 6inch and 8inch, two swivel and two fixed​
  • High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose


Safety Precautions​:
1. The operation voltage on the platform is 24V
2. Emergency stop button on the platform and ground
3. Auxiliary platform lowering
4. Hose burst valve safety
5. Rain-proof design electric cabinet
6. Fold-able fence on the platform



Applications:

1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.

2. Aerial Working Purpose: machine maintenance, painting, cleaning etc.



Why choose CHEN LIFT Mobile Scissor Lift?

  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

Mini Mobile Scissor Lift 3 Meters High 240kg Loading Capacity Easy Operation 0



Communication with Customers:

A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?

B: The main difference is from the structure and the material

The scissor lift is in scissor structure with steel material

The aerial work platform is in mast structure with aluminum material



A: How is that for quality control in your factory?

B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly

1.Strict quality control system on the whole process of production

2.Imported key arts to ensure the high quality of our products

3.Advanced equipment and tools for examination and quality control

4.100% strict examining products before shipment

5.All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.



A: What is the delivery time for your goods?

B: it is 30days after order confirmation



A: What spare parts that you can offer?

B: We provide following spare parts freely for your maintenance of the machine:

Item Quantity
Fuse 3
"O" Rubber Seals Φ11 3
Wrench 1
Pressure Oiler 1
Cross Screwdriver 1
Straight Screwdrive 1



A: How long is your quality guarantee period?

B: We have one year warranty.
