Home ProductsMobile Scissor Lift

Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving

Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving

    • Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving
    • Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving
    • Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving
  • Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving

    Product Details:

    Place of Origin: CHINA
    Brand Name: XUNTE
    Certification: ISO9001:2008
    Model Number: SJY0.45-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIABLE
    Packaging Details: PALLETS
    Delivery Time: 30 DAYS
    Supply Ability: 100 SETS PER MONTH
    Contact Now
    Detailed Product Description
    Loading Capacity: 450kg Platform Height: 12m
    Working Height: 14m Platform Size: 2450*1350mm
    Extension Length: 800mm Extension Load: 100kg
    Lifting Power: 3kw Lifting Time: 125s
    Weight: 2450kg Measurement: 2650*1550*1880mm



    Ware House Using Motorized Scissor Lift 12m platform Height DC Lifting and Moving





    Quick Detail:



    Name

    Electrically Driven Wheel Type 12m Movable Hydraulic Scissor Platform

    Loading Capacity

    450Kg

    Platform Height

    12m

    Platform Size

    2450*1350mm

    Color

    Red Color

    Driven Power

    0.75Kw

    Power Supply

    DC

    Measurement

    2650*1550*1880mm

    Lifting Time

    125s

    Oil Cylinder

    Ø100(3Pcs)

    Lifting Power

    3Kw

    Extension Load

    100Kg

    Extension Length

    800mm



    Description:



    As the general weight of the machine is more than one ton, with electrically driven wheel design can save man power a lot. The extension platform can enlarge the working space, and there is no need to move the machine when the other place is within 1 m to the current location.





    Applications:



    1. Site: Logistic Center, Ware House, Factory.

    2. Aerial Working Purpose: enable people to work in the heights, people can do works on the platform like amend or paint walls, install or maintenance facilities.





    Main Features:



    1. Stable scissor arm structure.

    2. Fine gridding cylinders

    3. Two sets of control panels to suite different using purpose.

    4. Detachable fence, easy for passing narrow space.

    5. With electrically driven wheel for easy transaction.

    6. Extension Platform





    Safety Precaution:



    1. 24V working voltage on the platform to guarantee the people’s safety.

    2. With Emergency stop button on both platform and ground control boxed in case of something emergency happens

    3. Detachable outriggers to adjust the horizontal level

    4. Auxiliary Lowering Device on the chassis to let the platform lower down when power failure.

    5. 1.2m height fence on the platform

    6. Moving switch, when the machine lifts, the motorized can not be moved.





    Configurations:

    • Electric system: Schneider contactor, SANLICO button, CHNT electrical

    • Hydraulic System: Hycman brand power pack ,NOK sealing

    • Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B

    • Platform Surface : Antiskid checkered plate

    • Tire: Ø500-8 Inflated tires

    • High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose :

      Optional Configuration:

    • Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher

    • Rubber Solid Tire

    • Flame Proof Control Cabinet



      Why to choose Xunte Push around Hydraulic Scissor Lift Platform?



    • High Quality---We have experienced workers and strict quality department. The material we use must choose reliable supplier.

    • Reasonable price---our price can match up with our quality

    • Good after sale service---One year Warranty and a set of easy damage parts shipped along side with the machine, we promise to reply you within 24 hours since you get your information about the machine.
