|Place of Origin:||China|
|Model Number:||SJG 5-1.85|
|Minimum Order Quantity:||1 set|
|Packaging Details:||Wrapped in pallet|
|Delivery Time:||30 days|
|Payment Terms:||T/T L/C|
|Supply Ability:||100 sets/month|
|Loading Capacity:||5000kg||Lifting Height:||1.85m|
|Platform Size:||5000*2000mm||Lifting Power:||5.5 Kw|
5000Kg Loading Roller Custom Vertical Lift Table For Work Shop Theatre
|Name||Roller Custom Lift Platform||Brand Name||Xunte|
|Loading Capacity||5000Kg||Lifting Height||1.85m|
|Lifting Power||5.5 Kw||Power Supply||
Main Characters of Roller Lift Platform:
Roller Custom Lift platforms are equipped with mechanical drive or electric drive roller –way to transfer goods vertically and horizontally.
1. Easily installation and maintenance
2. Excellent mechanical structure, which works in lower initial lifting height with maximum lifting stroke.
3. The antiskid design endows the platforms with excellent antiskid property
4. Fine grinding cylinder in good sealing performance
5. Gas Shield Welding (in stronger hardness and everlasting)
6. Built-in pressure release valve
7. Auxiliary platform lowering when electricity off
8. Oil less bearing mounted in the joint parts, pin roll with grease fitting.
9. Overall hook by CNC torch flame cut
|Lifting Height||1.85 m|
Electric system:Schneider contactor, SANLICO button, CHNT electrical
Hydraulic System:Hycman brand power pack ,NOK sealing
Scissor Arm Support:Hi-strength Manganese steel rectangle tube Q345 B
Platform Surface:Antiskid checkered plate
High-pressure Oil Pip:Double wire hydraulic intensifier rubber hose
Power Supply: 3phases/380V/50HZ; DC 24V; manual pump
Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher
Flame Proof Control Cabinet
Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.
Aerial Working Purpose: machine maintenance, painting, cleaning etc.
Why to choose Xunte Hydraulic Lift Platform?
Good after Service
1 Year Warranty
More Than 10 Years Experience
Communication with Customers
A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?
B: The main difference is from the structure and the material
The scissor lift is in scissor structure with steel material
The aerial work platform is in mast structure with aluminum material
A: How is that for quality control in your factory?
B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly
1.Strict quality control system on the whole process of production
2.Imported key arts to ensure the high quality of our products
3.Advanced equipment and tools for examination and quality control
4.100% strict examining products before shipment
5.All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.
A: What is the delivery time for your goods?
B: it is 30days after order confirmation
A: What spare parts that you can offer?
B: We provide following spare parts freely for your maintenance of the machine:
|"O" Rubber Seals Φ11||3|
A: How long is your quality guarantee period?
B: We have one year warranty.
