Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity

Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity

  • Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity
Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity
Product Details:
Place of Origin: China
Brand Name: CHEN LIFT
Certification: CE
Model Number: MK600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PVC Film Wrapped in Pallets or Wooden Case
Delivery Time: 30 days after order confirmed
Payment Terms: L/C, T/T
Supply Ability: 100 sets/ month
Contact Now
Detailed Product Description
Loading Capacity: 500kg Platform Height: 6m
Working Height: 8m Platform Size: 1.85*0.88m
Motor Power: 1.5kw Lifting Time: 54s
Weight: 650kg Overall Size: 1.90*1.12*0.75m
High Light:

scissor lift mobile

,

automobile scissor lift



Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity



Parameter:

Loading Capacity 500 Kg
Platform Height 6 m
Working Height 8 m
Platform Size 1850*880 mm
Motor Power 1.5kw
Power Voltage AC380V
Lifting Time 54s
Total Weight 650Kg
Overall Size 1900*1120*750mm



Description:

Manual Pushing Scissor Lift is a scissor structure man lift for aerial work which can be towed by man power.
It is for one or two persons aerial working purpose.
The maximum platform height is 3m, 6m, 7.5m, 9m, 11m, 12m, 14m, 16m.
And the maximum loading capacity is 300Kg, 500Kg, 1000Kg.
The mechanical structure make the platform stability, wide operating and high loading capacity.
Normal scissor lift lifting power is AC power, DC and both AC&DC power are also available for option.

Scissor lift platform is easily operated by the control box both on the platform and ground. The supporting legs can guarantee the stability of the lift. More safety for workers working on the platform with the guardrail. Besides the AC power, you also can add motorized device for assist walking.

Application for Scissor Lift
Scissor lift platform can be used in the factory, warehouse, public places, stations and so on.
It provides you a good choice for aerial working.



Standard Configuration for Manual Pushing Around Scissor Lift

  1. AC power: 220V 50Hz/60Hz, single phase, or 380V 50Hz/60Hz, three phases
  2. Rain-proof electric cabinet
  3. Beacon light
  4. Inflated Tyre
  5. Forklift slot
  6. Towing hook
  7. Chinese domestic brand hydraulic power pack
  8. Pressure gauge
  9. Auxiliary release valve
  10. Level gauge
  11. Emergency stop button both on platform and ground
  12. Key lock power switch
  13. Lockable stabilizer
  14. Anti-skid floor on platform with removable handrails
  15. Toe protection boards on the platform
  16. Operation voltage at 24V
  17. Ladders for access to the stowed platform (Ladder for easy accessibility)
  18. Limit switch provided for top motor shut off
  19. Removable control box on platform
  20. Interlock doors on platform
  21. Detachable/Foldable Fence
  22. Powder coating painting
  23. Spring mounted handles
  24. Nylon bush assembled in between each scissor
  25. Short Circuit and leakage protection system



Optional Configuration for Manual Pushing Around Scissor Lift

  1. Platform extension
  2. Overloading protection
  3. DC power supply
  4. Battery Indicator for DC power
  5. Hour meter for DC power
  6. AC&DC power supply
  7. Motorized device for easily pulling
  8. Horn available for motorized device
  9. Explosion proof type
  10. Maintenance supporting bar
  11. Solid Tyre
  12. Overseas brand hydraulic power pack
  13. Outrigger sensor
  14. Horn on the platform
  15. AC power to the platform
  16. Platform working light
  17. Anti-burst valve on cylinder



Main Features:
1. Pointing control of lifting up and down.
2. Manganese steel lifting arm in high strength with rectangle shape
3. Anti skid floor in platform
4 The control panels are available on the platforms and ground.
5. Fine grinding cylinder in good sealing performance
6. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.


Safety Precautions​:
1. The operation voltage on the platform is 24V
2. Emergency stop button on the platform and ground
3. Auxiliary lowering device
4. Hose burst valve safety
5. Rain-proof design electirc cabinet
6. Fold-able fence on the platform
7. Outrigger on the chassis for more stability​



Applications:

1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.

2. Aerial Working Purpose: machine maintenance, painting, cleaning etc.

Manual Pushing Mobile Scissor Lift Working Height 8 Meters 500Kg Loading Capacity 0



Our Service
1. We can design the customized the machines based on your requirement.
2. After knowing your detailed need, the right models will be recommended to you with good price.
3. Shipment can be arranged from our port to your destination port.
4. Operation video can be sent to you if needed.
5. Parts of machines can be sent to you by express within 7 days if needed.
