300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance

300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance

  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
  • 300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance
Product Details:
Place of Origin: CN
Brand Name: CHEN LIFT
Certification: CE ISO9001:2008 IPAF member
Model Number: FSEP3-3.3
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PVC Film Wrapped in Pallets or in wooden Case
Delivery Time: 30 days after order confirmed
Payment Terms: T/T or L/C
Supply Ability: 3000 Units Per Year
Contact Now
Detailed Product Description
Max. Platform Height: 3.3m Max Machine Height: 5m
Loading Capacity: 300kg Platform Size: 600*640 Mm
Lifting Motor: 24V/1.6kw Overall Weight: 450kg
High Light:

order picker platform

,

vertical order picker



300kg 3300mm Self-Propelled Powered Electric Aerial Order Picker

Product Description
Self-propelled Aerial Order Picker is the best equipment for materials picking and handling. It is widely used in warehouse and supermarket. Easy moving and poperating. Lift or fall steadily. Safe and reliable. Suitable for order picking application in distribution warehouse.

Self propelled aerial order picker is one kind of material handling equipment, it is mainly used to pick up cargo from rack. Operator can control moving, lifting and turning when stand on the platform, which highly improved the working efficiency. As it is lighter in weight, easy to implement by single person, flexible and convenient to operate, it is the best choice for stacking and reclaiming warehouses and supermarkets.

Self propelled order picker is equipped with two driving motor. Operator control the multi-function handle on the platform to make it move and turn.

Major Parameter of Self-propelled Aerial Order Picker

Model FSEP3-2.7 FSEP3-3.3 FSEP3-4.0 FSEP3-4.5
Loading Capacity 300Kg 300Kg 300Kg 300Kg
Max. Platform Height 2.70m 3.30m 4.00m 4.50m
Max. Machine Height 4.12m 5.00m 5.40m 6.00m
Platform Size 600*640mm 600*640mm 600*640mm 600*640mm
Stowed Length 1.53m 1.53m 1.62m 1.62m
Stowed Width 0.70m 0.70m 0.70m 0.70m
Stowed Height 1.83m 2.13m 1.84m 2.00m
Min. Turning Radius 1600mm 1600mm 1600mm 1600mm
Max. Climbing Capacity 15%-20% 15%-20% 15%-20% 15%-20%
Ground Clearance 40mm 40mm 40mm 40mm
Driving Motor 2*24V/0.4Kw 2*24V/0.4Kw 2*24V/0.4Kw 2*24V/0.4Kw
Lift Motor 24V/1.6Kw 24V/1.6Kw 24V/1.6Kw 24V/1.6Kw
Battery 2*12V/150Ah 2*12V/150Ah 2*12V/150Ah 2*12V/150Ah
Charger 24V/15A 24V/15A 24V/15A 24V/15A
Overall Weight 430Kg 450Kg 660Kg 680Kg


Configuration:
Proportional controls
Self-closing gate on platform
Drivable at full height
Non-marking tyre
Automatic brake system
Emergency lowering system
Emergency stop button
Cylinder holding valve
Forklift pockets
Charger protection
Flashing beacon

Structure Principle & Instruction
1. Charging the battery before you use it. After charging up the battery, please cut off the power, then unplug it.
2. Lift the platform to its top position to check that there is enough hydraulic oil in the system. Refill if necessary with YA-N32 or a similar oil.
3. Turn the key and switch on, the display indicator shows. Choose the mode of rising, control the height by Joy-stick.
4. Change the mode to walk. Also can be controlled by Joy-stick, the "rabbit" pattern indicates speed up, the "tortoise" pattern indicates speed down.

The structure of Self-propelled Aerial Order Picker is as below:
300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance 0
Product Details

300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance 1300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance 2

Company Introduction
As a subsidiary company of Bestmax Heavy Industry Company Limited, Chenlift (Suzhou) Machinery Co Ltd. Is a suzhou-based world-wide supplier of lifting equipment with over 20 years of experience in the lifting industry, we have the knowledge to assist you in acquiring your next lifting equipment.

300kg 3300mm Self Propelled Powered Electric Stock Picker High Performance 3
